Diesel Portable Piston Air Compressor Mobile for Jack Hammer
1.Simple structure,light weight,easy to move
2.Easy operating and maintenance.
3.High quality air delivery.
4.Superior technology,Low cost .
5.Valve plate and spring strip:made of special steel from Sweden and after special treatment.
6.Piston ring:special design;integral casting;excellent flexibility;lowest lubricating oil consumption
7.Cylinder:made of boron cast iron;wear resistant;special suitable for dusty condition
8.Cylinder cover:extrusion process adopted;streamlined external appearance;good heat emission performance.
9.High efficiency and low consumption.
10.Stable and smooth running with anti-vibration frame.
11.Professional design and Special manufacturing.
7.Energy saving.
| Model | Power | Capacity/8bar | Size(H*L*W) | Weight | Phase | Frequency/380V/220V |
| LV2008 | 1.5KW | 170L/min 6CFM | 88*35*68cm | 60kg | single/3 | 50HZ/60HZ/380V/220V |
| LV3008 | 2.2KW | 250L/min 9CFM | 98*38*80cm | 70kg | single/3 | 50HZ/60HZ/380V/220V |
| LV4008 | 3.0KW | 360L/min 13CFM | 107*38*84cm | 83kg | single/3 | 50HZ/60HZ/380V/220V |
| LV5508 | 4.0KW | 450L/min 16CFM | 121*38*87cm | 105kg | single/3 | 50HZ/60HZ/380V/220V |
| LV7508 | 5.5KW | 670L/min 24CFM | 136*50*98cm | 148kg | single/3 | 50HZ/60HZ/380V/220V |
| LV10008 | 7.5KW | 900L/min 30CFM | 136*50*98cm | 160kg | single/3 | 50HZ/60HZ/380V/220V |
